MIBU-293-01 Multi-Channel Interface Breakout Module 82099862-001, 16-Channel PCB Mounting

The MIBU-293-01 Multi-Channel Interface / Breakout Module, part number 82099862-001, is a specialized industrial interface PCB designed to provide organized access to multiple signal connections.

As shown in the product image, the module features 16 individually identified channel connections, CN1 through CN16, together with two large interface connectors identified as J1 and J2. The board incorporates multiple connector blocks and resistor networks to provide a structured breakout/interface arrangement between the main connectors and individual channel connections.

The MIBU-293-01 82099862-001 is suitable for industrial control, automation, instrumentation and system-interface applications where multiple signals need to be routed through an organized breakout assembly. The clearly marked channel positions can simplify wiring, inspection, maintenance and troubleshooting.

This module is particularly useful as a replacement, spare or service component for compatible industrial control equipment. Before installation, users should verify the exact system compatibility, connector pinout, electrical ratings and application requirements against the original equipment documentation.
