Siemens 6ES7215-1HG40-0XB0 SIMATIC S7-1200 CPU 1215C DC/DC/Relay Compact PLC

Name: Siemens 6ES7215-1HG40-0XB0 SIMATIC S7-1200 CPU 1215C DC/DC/Relay Compact PLC
Brand: Siemens
SKU: 1333
Availability: InStock

Pricing Status

NEW

Specification Details
Manufacturer: Siemens AG
Series: SIMATIC S7-1200
Part Number: 6ES7215-1HG40-0XB0
Supply Voltage: 20.4 V DC to 28.8 V DC
Digital Inputs: 14 (24 V DC, sinking/sourcing)
Digital Outputs: 10 (Relay type, changeover, max 2 A)
Analog Inputs: 2 (0 to 10 V DC)
Analog Outputs: 2 (0 to 20 mA)
High-Speed Counters: 6 counters max (up to 100 kHz)
Dimensions: 130 mm x 100 mm x 75 mm (W x H x D)
Ambient Operating Temperature: -20 °C to 60 °C
Status:- New (As Per Photos)
Country of Origin: Made in China
Shipping:- Fast & Safe Worldwide Shipping Available.

chat WhatsApp

verified_user

Free Shipping

For Indian customers

verified_user

Secure Payment

100% protected

verified_user

Export Quality

Authentic & Certified

verified_user

Fast Delivery

Worldwide shipping

The Siemens SIMATIC S7-1200 CPU 1215C (6ES7215-1HG40-0XB0) is the definitive choice for compact automation solutions requiring comprehensive onboard I/O capabilities and fast data processing. Operating on a 24V DC power supply, it safely routes outputs through 10 heavy-duty relay contacts capable of switching up to 2A loads.

This controller bridges the gap between basic and advanced automation systems. Its integrated analog capabilities (2 inputs and 2 outputs) remove the need for expensive expansion cards in simple temperature, pressure, or speed-control loops. Configured through the intuitive Siemens TIA Portal Software, this CPU minimizes engineering time while maximizing system security, diagnostic efficiency, and machine uptime.
