Siemens 6SL3040-1MA01-0AA0 CU320-2 Control Drive Module

Name: Siemens 6SL3040-1MA01-0AA0 CU320-2 Control Drive Module
Brand: Siemens
SKU: 1903
Availability: InStock

Pricing Status

USED

Specification Details
Brand: Siemens
Model: CU320-2 PN Control Unit
Part Number: 6SL3040-1MA01-0AA0
Product Type: PN Control Unit Drive Module
Input Electronic Supply: 24V DC
Rated Supply Current: 1.0 A
Maximum Total Output Current: 5.5 A
Digital Inputs: 12 channels
Bidirectional Digital I/O: 8 channels
DRIVE-CLiQ Interfaces: 4 ports
Operating Temperature: 0°C to +55°C
Max Operating Altitude: 2,000 meters above sea level
Net Dimensions: 50.0 mm x 300.0 mm x 226.0 mm
Net Weight:2.20 kg
Status:- Used Good Working (As Per Photos)
Country of Origin: Made in Germany
Shipping:- Fast & Safe Worldwide Shipping Available.

chat WhatsApp

verified_user

Free Shipping

For Indian customers

verified_user

Secure Payment

100% protected

verified_user

Export Quality

Authentic & Certified

verified_user

Fast Delivery

Worldwide shipping

The Siemens SINAMICS CU320-2 PN (6SL3040-1MA01-0AA0) is an advanced industrial control module that provides centralized intelligence for high-demand, multi-axis drive applications. Acting as the core brain of the SINAMICS S120 drive framework, it handles open-loop and closed-loop speed control, motion vectors, and complex positioning operations simultaneously across multiple independent machine axes.

Equipped with a dual-port PROFINET connection and support for EtherNet/IP, the CU320-2 PN allows fast, cyclic data communication to modern PLCs and distributed control architectures. Its hardware interface includes 12 digital inputs, 8 configurable bidirectional digital I/O channels, 4 high-speed DRIVE-CLiQ ports for digital motor and encoder interfaces, an RS232 serial connection, 3 physical analog measuring sockets, and 1 option slot for functionality expansions.

Operating on a reliable 24V DC power feed, this rugged module features efficient thermal dissipation within a slim 50mm space-saving profile.
